　Hale valve
Welcome to Hale valve

Note:

1.Design and manufacture:Manufacturer Standard.

2.End connection:ASME BI.20.3.

3.Test and inspection:API 598.

6.Size up to 2"-6".

Materials list:

1 Shaft "0" ring NBR / EPDM
2 Body D.I.+Nickel Plated
3 Disc Bronze
4 Disc "0" ring NBR / EPDM / Viton
5 Disc bolt Stainless steel
6 "0" ring NBR / EPDM / Viton
7 Shaft Stainless steel
8 Lever ball Ball bearing steel
9 Lever spring Stainless steel
10 Lever Ductile iron
DN H1 H2 H3 L1 L2 L3
50 57.2 120.7 76.2 108 203.2 88
80 69.9 154 103.2 123.8 203.2 119
100 93.7 161.9 134.9 130.2 203.2 155.8
150 120.7 238.1 196.9 177.8 330.2 277.4
